Kubota Powered Mini Skid Steer Loader with Crawler Undercarriage & Diesel Engine 2-Year Warranty PLC Core Components
Tracked Stand on Skid Steer Loader Brand NewSkid Steer Loader
The compact machine is equipped with a powerful engine and advanced hydraulic system, which performs well in easily lifting, excavating, and moving materials.
It is also possible to meet various work needs by replacing different accessories such as forks, buckets, snow sweepers, etc., making it an ideal choice for urban construction sites and residential areas.
| Engine Model | Runtong R740D | Overall Vehicle Height | 1300mm |
|---|---|---|---|
| Rated Power | 16.8 kW/3600 rpm | Overall Length with Standard Bucket | 2229mm |
| Cylinders | 2 | Vehicle Width | 1024mm |
| Intake Method | Naturally aspirated | Overall Length without Bucket | 1700mm |
| Emission Standard | EPA/EURO5 | Bucket Width | 1070mm |
| Rated Load | 350 kg | Rear Length | 220mm |
| Maximum Load | 480 kg | Maximum perating Height | 2561mm |
| Maximum Lifting Force | 5.5 kN | Height to Bucket Pin | 2071mm |
| Bucket Capacity | 0.12 m³ | Maximum Bucket Square Height | 2024mm |
| Travel Speed | 0-4 km/h | Dump Height | 1376mm |
| Working Three-Phase | 9 s | Dump Distance | 231mm |
| Working System Pressure | 16 bar | Wheelbase | 800mm |
| Fuel Tank Capacity | 21 L | Ground Clearance | 195mm |
| Gross Vehicle Weight | 976 kg | Bucket Tilt Angle at Ground Level | 25° |
| Track Model | 180*72*35 | Bucket Tilt Angle at Maximum Height | 88° |
